Performing a Bare Metal Installation of Fedora Atomic
Fedora Atomic can be thought of as a Fedora instance of the Project Atomic pattern. This document shows how to perform a bare metal installation of Fedora Atomic from physical media. The installation is guided by the Anaconda tool that is also used in Fedora and Red Hat Enterprise Linux. If you are familiar with the Anaconda GUI, you will find the installation process very similar.
Getting the Installation Image and Creating Media
Download the boot.iso file from GetFedora.org and use it to create installation media. For example, if you run the GNOME desktop, you can use the Write to disk capability of the Nautilus file browser to create an installation DVD. Alternatively, you can write the installation ISO image to a USB device with the
dd command. For example, if you had a USB thumbdrive mounted as
/dev/sdb, you might use this command (be careful to get the drive location right):
dd if=Fedora-Atomic-ostree-x86_64-27-20171110.1.iso of=/dev/sdb bs=4M
These procedures are described in the Fedora Installation guide in the second chapter called Making media.
Installing Fedora Atomic with the Anaconda Installer
Disconnect any drives which you do not need for the installation, power on your computer system and insert the installation media you created from boot.iso. Then, power off the system with the boot media still inside, and power on the system again. Note that you might need to press a specific key or combination of keys to boot from the media or configure your system’s Basic Input/Output System (BIOS) to boot from the media.
Once your system has completed booting, the boot screen is displayed:
The boot media displays a graphical boot menu with three options:
Install Fedora-Atomic 27 - Choose this option to install Fedora Atomic onto your computer system using the graphical installation program.
Test this media & install Fedora-Atomic 27 - With this option, the integrity of the installation media is tested before installing Fedora Atomic onto your computer system using the graphical installation program. This option is selected by default.
Troubleshooting - This item opens a menu with additional boot options. From this screen you can launch a rescue mode for Fedora Atomic, or run a memory test. Also, you can start the installation in the basic graphics mode as well as boot the installation from local media.
If no key is pressed within 60 seconds, the default boot option runs. Press Enter to proceed.
After media check, you are directed to the welcome screen. This interactive install is exactly the same as installing standard Fedora Server, so you can use Fedora’s guide to the Anaconda GUI.
The one thing which is different is disk partitioning. Post-install, Atomic will automatically use some of the unused space on your primary LVM partition to create a Docker pool partition. You will need this partition in order to have space for containers. As such, we recommend leaving half your available disk space as unallocated LVM partition space.
Once you configured all required settings, the orange warning signs disappear and you can start the installation by pressing Begin Installation.
While the installation proceeds, you can specify user settings, such as a root password and adding one or more system users. We strongly recommend that you do both, as Atomic Host has no GUI login and you will be unable to log in without one or more valid user logins. When the installation is finished, you are prompted to reboot the system by pressing Reboot.
Kickstart installations offer a means to automate the installation process, either partially or fully. Kickstart files contain answers to all questions normally asked by the installation program, such as what time zone do you want the system to use, how should the drives be partitioned or which packages should be installed.
The installer ISO contains embedded content, and thus works offline. However, to do a PXE installation, you must download the content dynamically. We strongly recommend mirroring the OSTree repository, rather than having each machine contact the upstream provider.
So, for unattended installation you need to specify your own kickstart configuration and load it from the boot prompt as described below. Use the
ostreesetup command in your custom configuration, which is what configures anaconda to consume the rpm-ostree generated content.
For example, create atomic-ks.cfg file with the following content, for Fedora Atomic 27:
lang en_US.UTF-8 keyboard us timezone America/New_York zerombr clearpart --all --initlabel autopart # sudo user with an ssh key (use your key) user --name=atomic --groups=wheel --sshkey="ssh-rsa AAAAB3NzaC1yc2EAAAA ..." # NOTICE: This will download the the latest release from upstream, which could be slow. ostreesetup --nogpg --osname="fedora-atomic" --remote="fedora-atomic-26" --url="https://kojipkgs.fedoraproject.org/atomic/27" --ref="fedora/27/x86_64/atomic-host" # Alternately, install from the ISO media: # ostreesetup --osname="fedora-atomic" --remote="fedora-atomic-27" --url="file:///ostree/repo" --ref="fedora/27/x86_64/atomic-host" --nogpg # however, you will need to reset ostree setup afterwards in %post
There are several other options you can specify in the kickstart file, see Kickstart Options in the Fedora Installation guide, or this blog post which shows a more complex configuration with disk partitioning.
After creating the configuration file, you have to ensure that it will be available during the installation. Place the file on hard drive, network, or removable media as described in the Fedora Installation guide. As a simple example, if the kickstart file is on another machine in the same network, you could serve it using a simple HTTP server:
cd kickstart/ python -m SimpleHTTPServer
Start the installation as described above. On the grub menu screen, press the up arrow to select
Install Fedora. Then press
e to edit this option. You will see a
linuxefi line which boots the install kernel; edit this line to add a kickstart file location after the directive
inst.ks. If we were serving the kickstarter file on the network with SimpleHTTPServer as above, for example, we would do this:
linuxefi /images/pxeboot/vmlinuz inst.stage2=hd:LABEL=Fedora-Atomic-26-x86_64 inst.ks=http://192.168.1.105:8000/atomic-ks.cfg inst.text quiet
See the Fedora Installation guide for more information on how to start a kickstart installation.
With the kickstart file described above, the installation proceeds automatically until Anaconda reboots the system after finishing the installation. This can be more fully automated if you use a PXEboot server, which can serve up both the OS images and the kickstart file.
There is also a kickstart file in repository https://pagure.io/fedora-kickstarts
Updating and Reverting Fedora Atomic
NOTE: If you’ve used a different
ostreesetup URL or reference, you’ll want to make sure you set the appropriate repository to get updates. If the
ostreesetup URL is where you’d like to receive updates, you can skip the
To receive updates for your Fedora Atomic installation, specify the location of the remote OSTree repository. Execute:
# ostree remote add --if-not-exists \ # --set=gpgkeypath=/etc/pki/rpm-gpg/RPM-GPG-KEY-fedora-27-primary \ # fedora-atomic-27 https://kojipkgs.fedoraproject.org/atomic/27
Here, fedora-atomic-27 is used as a name for the remote repository. The URL is stored in the /etc/ostree/remotes.d/fedora-atomic.conf configuration file. While GPG key checking is optional, it’s highly recommended to prevent spoofing of installation files. A new GPG key is required for each major Fedora release at this time, but that will change when Atomic shifts to rolling upgrades.
Now you are able to update your system with the following command:
# rpm-ostree rebase fedora-atomic:
rebase command, that is an extension of the
upgrade command, switches to a newer version of the current tree. In the above syntax, fedora-atomic: stands for the full branch name (in this case fedora-atomic/rawhide/x86_64/server/docker-host). Reboot the system to start the updated version of Fedora Atomic:
# systemctl reboot
To determine what version of the operating system is running, execute:
# atomic host status
To revert to a previous installation, execute the following commands:
# atomic host rollback # systemctl reboot
